| HDT Low-voltage cables for automobiles |
Description：
HDT：Heavy duty， Thermoplastic insulated
Application：
Wire harness of low-tension electric circuits for automobiles
Material：
Conductor：Annealed or tinned stranded copper
Insulation：Lead-free polyvinyl chloride (-40～80°C)
Standard：SAE J 1128 |
 |
|
Conductor |
Insulation thickness |
Overall diameter |
Weight |
Package |
|
Size |
Construction |
sectional area |
Diameter |
Standard |
Minimum |
Standard |
Maximum |
|
AWG |
No./mm |
mm2 |
mm |
mm |
mm |
mm |
mm |
kg / km |
m |
|
20 |
7/0.32 |
0.508 |
0.98 |
0.91 |
0.64 |
2.80 |
3.10 |
13 |
500 |
|
18 |
19/0.23 |
0.760 |
1.16 |
0.94 |
0.66 |
3.04 |
3.40 |
16 |
500 |
|
16 |
19/0.28 |
1.12 |
1.41 |
1.02 |
0.71 |
3.45 |
3.70 |
22 |
500 |
|
14 |
19/0.36 |
1.85 |
1.81 |
1.04 |
0.73 |
3.89 |
4.20 |
31 |
200 |
|
12 |
19/0.45 |
2.91 |
2.26 |
1.17 |
0.82 |
4.60 |
5.10 |
46 |
200 |
|
10 |
19/0.57 |
4.65 |
2.87 |
1.17 |
0.82 |
5.21 |
5.70 |
66 |
200 |
|
8 |
19/0.72 |
7.23 |
3.62
|
1.40 |
0.98 |
6.42 |
7.00 |
103 |
100 | |
|
|
