| AVSS Low tension cables with thin wall insulation for automobiles |
Description：
A：Low-voltage cables for automobiles
V：Vinyl insulated
SS：Super thin-wall type
Application： Wire harness of low voltage electric circuits for automobiles
Material：
Conductor：Annealed or tinned stranded copper
Insulation：Lead-free polyvinyl chloride (80°C)
Standard：Japanese Automobile Standard：JASO D 611 |
 |
|
Conductor |
Insulation thickness |
Overall diameter |
Conductor
resistance |
Weight |
Package |
|
Size |
Construction |
Sectional area |
Diameter |
Standard |
Minimum |
Standard |
Maximum |
|
mm2 |
No./mm |
mm2 |
mm |
mm |
mm |
mm |
mm |
mΩ/ m |
kg / km |
m |
|
0.3 |
7/0.26 |
0.3716 |
0.8 |
0.30 |
0.24 |
1.4 |
1.5 |
50.2 |
5 |
500 |
|
0.5 |
7/0.32 |
0.5629 |
1.0 |
0.30 |
0.24 |
1.6 |
1.7 |
32.7 |
6 |
500 |
|
0.85 |
19/0.24 |
0.8596 |
1.2 |
0.30 |
0.24 |
1.8 |
1.9 |
21.7 |
10 |
500 |
|
0.85 |
7/0.40 |
0.8796 |
1.1 |
0.30 |
0.24 |
1.8 |
1.9 |
20.8 |
10 |
500 |
|
1.25 |
19/0.29 |
1.255 |
1.5 |
0.30 |
0.24 |
2.1 |
2.2 |
14.9 |
13 |
500 |
|
2 |
19/0.37 |
2.043 |
1.9 |
0.40 |
0.32 |
2.7 |
2.8 |
9.00 |
20 |
200 |
|
0.3f |
19./0.16 |
0.3821 |
0.8 |
0.3 |
0.24 |
1.4 |
1.5 |
48.8 |
5 |
500 |
|
0.5f |
19/0.19 |
0.5387 |
1.0 |
0.3 |
0.24 |
1.6 |
1.7 |
34.6 |
6 |
500 |
|
0.75f |
19/0.23 |
0.7895 |
1.2 |
0.3 |
0.24 |
1.8 |
1.9 |
23.6 |
9 |
500 |
|
1.25f |
37/0.21 |
1.282 |
1.5 |
0.3 |
0.24 |
2.1 |
2.2 |
14.6 |
13 |
500 |
|
2f |
37/0.26 |
1.964 |
1.8 |
0.4 |
0.32 |
2.6 |
2.7 |
9.50 |
20 |
200 |
|
Remarks：f in nominal sectional area indicates flexible |
|
|
|
