| AV Low-voltage cables for automobiles |
Description：
A：Low-voltage cables for automobiles
V：Vinyl insulated
Application：Wire harness of low-tension electric circuits for automobiles
Material：
Conductor：Annealed or tinned stranded copper
Insulation：Lead-free polyvinyl chloride (80°C)
Standard：Japanese Industrial Standard：JIS C 3406 |
 |
|
Conductor |
Insulation
thickness |
Overall diameter |
Conductor
resistance |
Weight |
Package |
|
Size |
Construction |
Sectional area |
Diameter |
Standard |
Maximum |
|
mm2 |
No./mm |
mm2 |
mm |
mm |
mm |
mm |
Ω/ km |
kg / km |
m |
|
0.5f |
20/0.180 |
0.5087 |
1.00 |
0.60 |
2.20 |
2.40 |
36.70 |
8 |
500 |
|
0.5 |
7/0.320 |
0.5629 |
1.00 |
0.60 |
2.20 |
2.40 |
32.70 |
9 |
500 |
|
0.75f |
30/0.180 |
0.7630 |
1.20 |
0.60 |
2.40 |
2.60 |
24.40 |
12 |
500 |
|
0.85 |
11/0.320 |
0.8846 |
1.20 |
0.60 |
2.40 |
2.60 |
20.80 |
12 |
500 |
|
1.25f |
50/0.180 |
1.273 |
1.50 |
0.60 |
2.70 |
2.90 |
14.70 |
17 |
500 |
|
1.25 |
16/0.320 |
1.287 |
1.50 |
0.60 |
2.70 |
2.90 |
14.30 |
17 |
500 |
|
2.0 |
26/0.320 |
2.091 |
1.90 |
0.60 |
3.10 |
3.40 |
8.81 |
25 |
200 |
|
3.0 |
41/0.320 |
3.297 |
2.40 |
0.70 |
3.80 |
4.10 |
5.59 |
39 |
200 |
|
5.0 |
65/0.320 |
5.228 |
3.00 |
0.80 |
4.60 |
4.90 |
3.52 |
60 |
200 |
|
8.0 |
50/0.450 |
7.952 |
3.70 |
0.90 |
5.50 |
5.80 |
2.32 |
90 |
100 |
|
Remarks：f in nominal sectional area indicates flexible | |
|
|
